VISOR
®
Communications manual
Parameter name
Parameter
number
Value Length Format
unit * 1000)
1: Y axis offset (in user
unit * 1000)
2: Z axis offset (in user
unit * 1000)
3: X rotation (in
degrees * 1000)
4: Y rotation (in
degrees * 1000)
5: X rotation (in
degrees * 1000)
per value integer
Transformation calibration
coordinate system
012
0: X axis offset (in user
unit * 1000)
1: Y axis offset (in user
unit * 1000)
2: Z axis offset (in user
unit * 1000)
3: X rotation (in
degrees * 1000)
4: Y rotation (in
degrees * 1000)
5: X rotation (in
degrees * 1000)
8 bytes
per value
Signed
integer
Transformation
measurement coordinate
system
014
0: X axis offset (in user
unit * 1000)
1: Y axis offset (in user
unit * 1000)
2: Z axis offset (in user
unit * 1000)
3: X rotation (in
degrees * 1000)
4: Y rotation (in
degrees * 1000)
5: X rotation (in
degrees * 1000)
8 bytes
per value
Signed
integer
Z Offset 021
Value in user unit (see
unit * 1000)
8 Byte
Signed
integer
Focal length 022 (in mm *1000) 8 Byte
Signed
integer
Page 157 EN 06814859 - 1/24/2019-00
