RUGGEDCOM ROS
User Guide
Chapter 4
System Administration
Configuring the RADIUS Client 129
Figure72:RADIUS Server Table
2. Select either Primary or Backup from the table. The RADIUS Server form appears.
7
6
5
4
3
2
1
Figure73:RADIUS Server Form
1.Server Box 2.IP Address Box 3.Auth UDP Port Box 4.Auth Key Box 5.Confirm Auth Key Box 6.Apply Button 7.Reload
Button
3. Configure the following parameter(s) as required:
Parameter Description
Server Synopsis:  Any 8 characters
Default:  Primary
This field tells whether this configuration is for a Primary or a
Backup Server.
IP Address Synopsis:  ###.###.###.### where ### ranges from 0 to 255
The Server IP Address.
Auth UDP Port Synopsis:  1 to 65535
Default:  1812
The IP Port on server.
Auth Key Synopsis:  31 character ASCII string
The authentication key to be shared with server.
Confirm Auth Key Synopsis:  31 character ASCII string
The authentication key to be shared with server.
4. Click Apply.
