RUGGEDCOM ROS
User Guide
Chapter 3
Device Management
Viewing CPU Diagnostics 53
Parameter Description
Rev C1), RSG2100, RS900G, RSG2200, RS969, RS900 (v2,
40-00-0066), RS900 (v2, 40-00-0067), , RS416 (40-00-0078),
RMC30 (v2), RS930 (40-00-0089), RS969 (v2, 40-00-0090), RS910
(40-00-0091-001 Rev A), RS920L (40-00-0102-001 Rev A), RS940G
(40-00-0097-000 Rev A), RSi80X series CPU board, RSG2300,
RS416v2, ... }
Shows the type, part number, and revision level of the hardware.
Section3.2
Viewing CPU Diagnostics
To view CPU diagnostic information useful for troubleshooting hardware and software performance, navigate to
Diagnostics» View CPU Diagnostics . The CPU Diagnostics form appears.
Figure9:CPU Diagnostics Form
1.Running Time Box 2.Total Powered Time Box 3.CPU Usage Box 4.RAM Total Box 5.RAM Free Box 6.RAM Low Watermark
Box 7.Temperature Box 8.Free Rx Bufs Box 9.Free Tx Bufs Box 10.Reload Button
This screen displays the following information:
Parameter Description
Running Time Synopsis:  DDDD days, HH:MM:SS
The amount of time since the device was last powered on.
Total Powered time Synopsis:  DDDD days, HH:MM:SS
The cumulative powered up time of the device.
CPU Usage Synopsis:  0.0 to 100.0%
The percentage of available CPU cycles used for device operation as
measured over the last second.
RAM Total Synopsis:  0 to 4294967295
