Chapter 5
Setup and Configuration
RUGGEDCOM ROS
User Guide
232 Managing Port Security
Figure163:Static Multicast Groups Table
2. Select the group from the table. The Static Multicast Groups form appears.
7
5
6
3
2
1
4
Figure164:Static Multicast Groups Form
1.MAC Address Box 2.VID Box 3.Priority Box 4.Ports Box 5.Apply Button 6.Delete Button 7.Reload Button
3. Click Delete.
Section5.9
Managing Port Security
Port security, or port access control, provides the ability to filter or accept traffic from specific MAC addresses.
Port security works by inspecting the source MAC addresses of received frames and validating them against the list
of MAC addresses authorized by the port. Unauthorized frames are filtered and, optionally, the part that received
the frame can be shut down permanently or for a specified period of time. An alarm will be raised indicating the
detected unauthorized MAC address.
Frames to unknown destination addresses are flooded through secure ports.
CONTENTS
• Section5.9.1, “Port Security Concepts”
• Section5.9.2, “Viewing a List of Authorized MAC Addresses”
• Section5.9.3, “Configuring Port Security”
