Siemens RUGGEDCOM ROS v4.3 - Viewing Statistics for LLDP Neighbors

RUGGEDCOM ROS
User Guide
Chapter 5
Setup and Configuration
Viewing Statistics for LLDP Neighbors 215
Parameter Description
A number of times an entry was deleted from LLDP Neighbor
Information Table because the information timeliness interval has
expired.
Ageouts Synopsis:  0 to 4294967295
A counter of all TLVs discarded.
Section5.7.6
Viewing Statistics for LLDP Neighbors
To view statistics for LLDP neighbors, navigate to Network Discovery» Link Layer Discovery Protocol» View
LLDP Neighbor Information . The LLDP Neighbor Information table appears.
1
6
2
3
4
5
Figure148:LLDP Neighbor Information Table
1.Port Box 2.ChassisId Box 3.PortId Box 4.SysName Box 5.SysDesc Box 6.Reload Button
This form displays the following information:
Parameter Description
Port Synopsis:  1 to maximum port number
The local port associated with this entry.
ChassisId Synopsis:  Any 45 characters
Chassis Id information received from remote LLDP agent.
PortId Synopsis:  Any 45 characters
Port Id information received from remote LLDP agent.
SysName Synopsis:  Any 45 characters
System Name information received from remote LLDP agent.
SysDesc Synopsis:  Any 45 characters
System Descriptor information received from remote LLDP agent.
