RUGGEDCOM ROS
User Guide
Chapter 1
Introduction
Supported Proprietary RUGGEDCOM MIBs 13
Standard MIB Name Title
RFC 4318 RSTP-MIB Definitions of Managed Objects for Bridges with Rapid Spanning Tree
Protocol
RFC 3411 SNMP-FRAMEWORK-MIB An Architecture for Describing Simple Network Management
Protocol (SNMP) Management Framework
RFC 3414 SNMP-USER-BASED-SM-MIB User-based Security Model (USM) for Version 3 of the Simple
Network Management Protocol (SNMPv3)
RFC 3415 SNMP-VIEW-BASED-ACM-MIB View-bsed Access Control Model (VACM) for the Simple
Management Protocol (SNMP)
IEEE 802.3ad IEEE8023-LAG-MIB Management Information Base Module for Link Aggregation
IEEE 802.1AB-2005 LLDP-MIB Management Information Base Module for LLDP Configuration,
Statistics, Local System Data and Remote Systems Data Components
RFC 4363 Q-BRIDGE-MIB Definitions of Managed Objects for Bridges with Traffic Classes,
Multicast Filtering, and Virtual LAN Extensions
Section1.6.2
Supported Proprietary RUGGEDCOM MIBs
RUGGEDCOM ROS supports the following proprietary RUGGEDCOM MIBs:
File Name MIB Name Description
RUGGEDCOM-MIB.mib RUGGEDCOM-MIB RUGGEDCOM enterprise SMI
RUGGEDCOM-TRAPS-MIB.mib RUGGEDCOM-TRAPS-MIB RUGGEDCOM traps definition
RUGGEDCOM-SYS-INFO-MIB.mib RUGGEDCOM-SYS-INFO-MIB General system information about
RUGGEDCOM device
RUGGEDCOM-DOT11-MIB.mib RUGGEDCOM-DOT11-MIB Managemet for wireless interface on
RUGGEDCOM device
RUGGEDCOM-POE-MIB.mib RUGGEDCOM-POE-MIB Management for PoE ports on RUGGEDCOM
device
RUGGEDCOM-SERIAL-MIB.mib RUGGEDCOM-SERIAL-MIB Managemet for seral ports on RUGGEDCOM
device
RUGGEDCOM-STP-MIB.mib RUGGEDCOM-STP-MIB Management for RSTP protocol
Section1.6.3
Supported Agent Capabilities
RUGGEDCOM ROS supports the following agent capabilities for the SNMP agent:
NOTE
For information about agent capabilities for SNMPv2, refer to RFC 2580 [http://tools.ietf.org/html/
rfc2580].
