68 Viewing Statistics for All Ethernet Ports
Section3.6.3
Viewing Statistics for All Ethernet Ports
To view statistics collected for all Ethernet ports, navigate to Ethernet Stats» View Ethernet Statistics . The
Ethernet Statistics table appears.
Figure22:Ethernet Statistics Table
This table displays the following information:
Parameter Description
Port Synopsis:  1 to maximum port number
The port number as seen on the front plate silkscreen of the switch.
State Synopsis:  { ----, ----, Down, Up }
InOctets Synopsis:  0 to 4294967295
The number of octets in received good packets (Unicast+Multicast
+Broadcast) and dropped packets.
OutOctets Synopsis:  0 to 4294967295
The number of octets in transmitted good packets.
InPkts Synopsis:  0 to 4294967295
The number of received good packets (Unicast+Multicast+Broadcast)
and dropped packets.
OutPkts Synopsis:  0 to 4294967295
The number of transmitted good packets.
ErrorPkts Synopsis:  0 to 4294967295
The number of any type of erroneous packet.
Section3.6.4
Viewing Statistics for Specific Ethernet Ports
To view statistics collected for specific Ethernet ports, navigate to Ethernet Stats» View Ethernet Port Statistics
. The Ethernet Port Statistics table appears.
