Chapter 1
Introduction
RUGGEDCOM ROS
User Guide
22 ModBus Memory Formats
Address #Registers Description (Reference Table in UI) R/W Format
04F6 2 Port s8/p2 Statistics - Ethernet Out Packets R Uinst32
Serial Statistics
The following data is mapped to the uartPortStatus table:
Address #Registers Description (Reference Table in UI) R/W Format
0600 2 Port 1 Statistics – Serial In characters R Uint32
0602 2 Port 2 Statistics – Serial In characters R Uint32
0604 2 Port 3 Statistics – Serial In characters R Uint32
0606 2 Port 4 Statistics – Serial In characters R Uint32
0640 2 Port 1 Statistics – Serial Out characters R Uint32
0642 2 Port 2 Statistics – Serial Out characters R Uint32
0644 2 Port 3 Statistics – Serial Out characters R Uint32
0646 2 Port 4 Statistics – Serial Out characters R Uint32
0680 2 Port 1 Statistics – Serial In Packets R Uint32
0682 2 Port 2 Statistics – Serial In Packets R Uint32
0684 2 Port 3 Statistics – Serial In Packets R Uint32
0686 2 Port 4 Statistics – Serial In Packets R Uint32
06C0 2 Port 1 Statistics – Serial Out Packets R Uint32
06C2 2 Port 2 Statistics – Serial Out Packets R Uint32
06C4 2 Port 3 Statistics – Serial Out Packets R Uint32
06C6 2 Port 4 Statistics – Serial Out Packets R Uint32
Section1.8.3
ModBus Memory Formats
The following ModBus memory formats are supported by Siemens.
CONTENTS
• Section1.8.3.1, “Text”
• Section1.8.3.2, “Cmd”
• Section1.8.3.3, “Uint16”
• Section1.8.3.4, “Uint32”
• Section1.8.3.5, “PortCmd”
• Section1.8.3.6, “Alarm”
• Section1.8.3.7, “PSStatusCmd”
