Siemens RUGGEDCOM ROS v4.3 User Manual

Chapter 5
Setup and Configuration
RUGGEDCOM ROS
User Guide
146 Adding a Static VLAN
1
Figure86:Static VLANs Table
1.InsertRecord
2. Click InsertRecord. The Static VLANs form appears.
6
7
8
1
2
3
4
5
Figure87:Static VLANs Form
1.VID Box 2.VLAN Name Box 3.Forbidden Ports Box 4.IGMP Options 5.MSTI Box 6.Apply Button 7.Delete Button
8.Reload Button
3. Configure the following parameter(s) as required:
NOTE
If IGMP Options is not enabled for the VLAN, both IGMP messages and multicast streams will be
forwarded directly to all members of the VLAN. If any one member of the VLAN joins a multicast
group, then all members of the VLAN will receive the multicast traffic.
Parameter Description
VID Synopsis:  1 to 4094
Synopsis:  1 to 4094
Default:  1
