RUGGEDCOM ROS
User Guide
Chapter 5
Setup and Configuration
Configuring MAC Address Flooding Options 189
1. Navigate to MAC Address Tables» Configure MAC Address Flooding Options . The Flooding Options
table appears.
Figure116:Flooding Options Table
2. Select a port. The Flooding Options form appears.
Figure117:Flooding Options Form
1.Port(s) Box 2.Flood Unknown Unicast Options 3.Apply Button 4.Reload Button
3. Configure the following parameter(s) as required:
Parameter Description
Port(s) Synopsis:  Comma-separated list of ports
The port number as seen on the front plate silkscreen of the
switch (or a list of ports, if aggregated in a port trunk).
Flood Unknown Unicast Synopsis:  { On, Off }
Default:  On
Normally, unicast traffic with an unknown destination address is
flooded out of all ports. When a port is configured to turn off this
kind of flooding, the unknown unicast traffic is not sent out from
the selected port.
4. Click Apply.
