12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 187
Output Module Reference Data
E1/2048 kHz Output Module
Table 8-7 lists the failed output port number(s) for each possible hex digit. In the
above alarm message, the hex number is 00001. To determine the port in alarm,
locate the second row (corresponding to Hex Value 1) in Table 8-7. The right-most
column has an X, which corresponds to Port 20 (read across from Digit 5).
As another example, if the hex number is A501F, then the following ports are
squelched: 1 and 3 (corresponding to the A in Digit 1), 6 and 8 (corresponding to the
5 in Digit 2), 16 (corresponding to the 1 in Digit 4), and 17 through 20
(corresponding to the F in Digit 5).
Use the Alarm command to display the alarm information for a given module; the
display includes all E1/2048 kHz Output module alarms, including Alarm #10,
Squelching. Use the ALARM command (described in ICS Commands, on page 319)
or the SET-PRMTR- OUTE12048 command (described in TL1 Set Commands, on
page 304) to provision these alarms to Ignore, Report Only, Minor Alarm, Major
Alarm (default), or a Critical Alarm.
Table 8-7. Identifying Failed Ports from the Hex Digit
Hex Value
Digit 1
Digit 2
Digit 3
Digit 4
Digit 5
Port
1
5
9
13
17
Port
2
6
10
14
18
Port
3
7
11
15
19
Port
4
8
12
16
20
0––––
1–––X
2– – X –
3– – X X
4– X – –
5– X – X
6– X X –
7– X X X
8X–––
9X – – X
AX – X –
BX – X X
CX X – –
DX X – X
EX X X –
FX X X X
