Shelf Module Slot Addressing and Size Assignments

418 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004

Shelf Module Slot Addressing and Size Assignments

Table D-8 outlines the shelf module slot addressing and size assignments.

I/O Connector Grounding

Table D-9 outlines I/O connector grounding for all connectors.

Table D-8. Shelf Module Slot Addressing and Size Assignments

Slot-A Address Module Types Comments

1 1 Clock Clock A

2 2 Com Communications

3 3 I/O or Receiver Input, non-redundant Output, or a GPS

Receiver module

4 4 I/O, Output Pair A Input or Output, paired with 5

5 5 I/O, Output Pair A or Receiver Input, Output, paired with 4, or a GPS

Receiver module

6, 7 6, 7 I/O, Output Pair B Inputs or paired Output modules

8, 9 8, 9 I/O, Output Pair C Inputs or paired Output modules

10, 11 10, 11 I/O, Output Pair D Inputs or paired Outputs modules

12 - 15 I/O, Extras Reserved for future I/O

12 17 Clock Clock B

0 All Addresses all modules in the Shelf

Table D-9. I/O Connector Grounding

Name

Connector

Type

Reference

Description

Termination Type

Local OSC A BNC J1
