Symmetricom SSU-2000 User Manual

Composite Clock Output Module Default Settings
430 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
Composite Clock Output Module Default Settings
The Composite Clock Output module maintains factory default and current user
configuration settings. The configuration settings for the Composite Clock Output
Module are provided in
Table E-12.
RS-422 Output Module Default Settings
The factory default setting and range for all RS-422 Output module software
parameters are listed in
Table E-13 .
Table E-12. Composite Clock Output Module Configuration
Configuration Setting Factory Default Range
Port State Disabled Disabled/Enabled
Min Clock Acquire Acquire/Lock
Framing Not applicable Not applicable
Zero Suppression Not applicable Not applicable
CRC Not applicable Not applicable
SSM Not applicable Not applicable
PQL 4 Not applicable
Bypass On On/Off
Fault Action On Off/On/Auto
Duty Cycle 5/8 5/8 or 50/50
Table E-13. RS-422 Output Module Configuration
Configuration Setting Factory Default Range
Port State Disabled Disabled/Enabled
Min Clock Acquire Acquire/Lock
Framing Not applicable Not applicable
Bypass On On/Off
Fault Action On Off/On/Auto
Duty Cycle 50/50 5/8 or 50/50
