Product Overview
Communications Protocol
50 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
The SSU-2000 SNMP is an SNMP agent that requires Ethernet connectivity. If
SNMP is present, port 161 becomes the port of standard SNMP interactive
communications, while port 162 becomes the trap port. Since the SSU-2000 SNMP
supports all existing functions, full system control of the SSU-2000 is maintained
through SNMP.
The SSU-2000 implements an SNMP agent. A Management Information Base
(MIB) browser or the SNMP Manager is used to access, retrieve, and query
information defined by the MIB.
All reports, queries, autonomous messages, control, provisioning, and
administration (except for communication port parameters, Set User ID/Password,
Set IP assignments, Reset connection, and SNMP community settings) are
available through SNMP. Refer to SNMP Protocol, on page 384, for more
information.
Software Versions
There are six different versions of software available for the SSU-2000, as indicated
in Table 1-2. The functionality and commands that are available vary from one
version of software version to the next, depending on the specific features of the
software package and are described in Appendix B, Communications Protocol.
Graphical User Interface
SynCraft is a software interface program that is available to provide monitoring and
configuration functionality in a Microsoft Windows graphical user interface. Contact
your Symmetricom sales representative for more information on the SynCraft
Graphical User Interface, part number 14113245-000-0.
Table 1-2. Versions of Software for the Communications Module
Part Number Version TL1 ICS NTP
SNMP
v2
SNMP
v3
24113012-000-0 Basic System Load X X
24113012-001-0 Basic w/NTP Support X X X
24113012-002-0 Basic w/SNMP v2 Support X X X
24113012-003-0 Basic w/SNMP v2 and NTP
Support
XXXX
24113012-004-0 Basic w/SNMP v3 Support X X X
24113012-005-0 Basic w/SNMP v3 and NTP
Support
XXX X
