12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 401
Antennas
Installing Antennas
Antenna Installation Tools and Materials
These standard tools and materials are not supplied in the antenna kit, but may be
required for installing the GPS antenna. For a list of antenna kit contents, see Table
C-1.
Four each 0.25 inch (6 mm) fasteners for installing the antenna floor flange
Extra cable ties or acceptable cable clamps
#10 AWG (minimum) copper ground wire
Eight foot ground electrode
Custom mounting plates, U-bolts, masonry bolt, and so forth, as needed for
mounting to a tower, roof, or wall of a building
A cable puller may be required for installing the antenna coaxial cable
Digital voltmeter (DVM)
GPS Antenna Installation Procedures
This section provides installation procedures for installing the GPS antenna.
Preparing to Install the GPS Antenna
Before beginning to install the antenna, determine a grounding scheme, and
consider the factors that affect the location and environment chosen for the antenna
installation. These factors are addressed in the warnings, cautions, and
recommendations that follow.
Caution: To prevent damage to connectors, use caution while
pulling cable.
Note: Follow local building electrical codes when installing the GPS
antenna.
Caution: To avoid damage to the GPS antenna, do not place the
antenna where high-power radio signals are beamed directly at the
unit. Such signals can damage the preamplifier of the GPS antenna.
