TL1 Command Interface
272 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
where:
sid (Source Identifier) is the returned ID, and is the same as the tid in the input
command message
date is the current year, month, and day in the SSU-2000 in the format:
YY-MM-DD.
time is the current hours, minutes, and seconds timestamp information in the
SSU-2000 in the 24-hour format: HH-MM-SS
ctag (Correlation Tag) field is a six-digit alpha-numeric message identifier code
that is received with the command and returned in the response, for correlation of
message and response within the operating system
DENY is the deny message
ercd (Error Code) is a four-character error code that explains the reason for the
deny, and is one of the following defined codes (other error codes may be
defined and used, if required).
Autonomous Report Conventions
The SSU-2000 sends autonomous reports in response to a detected alarm
condition or status change. You can select one of two formats for autonomous
messages: GR-831 or GR-833. Use the RTRV-PRMTR-TL1FORMAT command to
select which format is generated. These reports are similar to the RTRV-ALARM
command responses, but contain an alarm code rather than the complied line.
The GR-831 format for an autonomous alarm report is:
<cr lf lf>
^^^sid^date^time <cr lf>
alrmcde^atag^REPT^ALM^[AIDTYPE]<cr lf>
^^^”aid:ntfcncde,condtype,srveff,ocrdat,ocrtm:condscr”<cr lf>
Table B-3. Denied Response Error Codes
Error Code Definition
ICNV Command Not Valid
IIAC Invalid aid Code
IICT Invalid ctag
IITA Invalid Target Identifier
IPEX Extra Parameter
IPMS Parameter Missing
IPNV Parameter Not Valid
SDNR Data Not Ready
