Antennas
Antenna Kits and Accessories
Table C-3. 26dB L1 GPS Antenna Accessory Kit
Part Number Description
12013076-xxx-0
(xxx = length)
Cable, LMR-400, 10 ft. to maximum of 190 ft. (Customer
specified length)
773000-0008 Transient Eliminator, 90 Volts, 1.5 GHz, N-Type
12013076-010-0 Cable, LMR-400, 10 ft., Right Angle
400302-0500 Roll, 3M 2150 Weatherproof Tape
Table C-4. 40dB L1 GPS Antenna Accessory Kit
Part Number Description
12013076-xxx-0
(xxx = length)
Cable, LMR-400, 70 ft. to maximum of 370 ft.
(Customer specified length)
773000-0008 Transient Eliminator, 90 Volts, 1.5 GHz, N-Type
12013076-030-0 Cable, LMR-400, 30 ft., Right Angle
551100-6013 Adapter, Right Angle Female to Right Angle Male
12010210-000-0 Bracket Assembly, Antenna Mount Right Angle
400302-0500 Roll, 3M 2150 Weatherproof Tape
12813080-000-0 Crimper Kit, LMR-400 (crimp tool, 2150 tape, LMR preptool,
10 each crimp N-type connectors)
Table C-5. 48dB and 68dB L1 GPS Antenna Accessory Kit
Part Number Description
12013076-xxx-0
(xxx = length)
Cable, LMR-400, 220 ft. to maximum of 970 ft. (Customer
specified length)
773000-0008 Transient Eliminator, 90 Volts, 1.5 GHz, N-Type
12013076-010-0 Cable, LMR-400, 30 ft., Right Angle
551100-6013 Adapter, Right Angle Female to Right Angle Male
12010210-000-0 Bracket Assembly, Antenna Mount Right Angle
570704-0001
(68 dB Output Only)
GPS L1 inline amplifier, Right Angle (required for lengths >
650 ft.)
400302-0500 Roll, 3M 2150 Weatherproof Tape
12813080-000-0 Crimper Kit, LMR-400 (crimp tool, 2150 tape, LMR preptool,
10 each crimp N-type connectors)
