Event Messages
260 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
Restart, in 5 seconds, COML\ 133 Module re-boot
Cannot Enable, CC Input Module,
COML\
134 Module cannot be enabled due to
configuration error
Zero Phase, B, COML\ 144 User has forced the phase to be cleared
Out of Window, Positive BPV 146 Positive BPV reversed
Sync Clock C, Start 147 Start syncing clock C to selected clock
Subtending On 148 Subtending mode is enabled
Port, Dis, COML\ 199 User has disabled the input
Priority 5, COML\ 201 User has changed the Priority setting
Prov PQL, 4, COML\ 203 User has changed the PQL to the setting
shown
Err Cnt, BPV, 16, COML\ 207 User has changed the BPV error threshold
Clr Cnt, BPV, 5, COML\ 208 User has changed the BPV clear threshold
IoName, Chg 224 User has changed the port name
Err Delay, (0), 10 sec, COML\ 251 User has changed the alarm delay time
Alm Level, (2), Maj, COML\ 252 User has changed the alarm level
Elevate Time, 86400 sec, COML\ 253 User has changed the alarm elevation time
Setup, Save, COML\ 254 User defaults have been set and saved
Table A-9. LRM Event Messages
Event Message Event # Event Description
Install, LRM Module 129 Module Installed
Remove, LRM Module 130 Module Removed
Enable, LRM Module, COML 131 Module Enabled
Disable, LRM Module, COML 132 Module Disabled
Restart, in 5 seconds, COML 133 User request for a module to reboot
CTA, Not Installed 145 Assembly not installed
Signal Path 146 Signal is through re-timer module or
cut-through
Port Cntl, Port[2-3], Disable, COML 193 Port control on ports 2 and 3 disabled
Table A-8. Input Module Event Messages (Continued)
Event Message Event # Event Description
