12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 231
Hardware Configuration Guide
Configuring a Subtending SSU
Installing Software
The Subtending SSU requires the software listed in Table 9-2:
To install the software you need to use either the SynCraft application or the
SSU-2000 Download application
Using the SynCraft Application
To use the SynCraft application to install software, refer to the on-line
documentation provided within the program.
Changing From Subtending SSU Mode
To change a Subtending SSU back to the normal mode:
1. Log in to the SSU-2000 and press the Enter key. The system prompt appears.
2. Type
opermode normal and press the Enter key. The system responds with:
2002-08-15-T15:57:56Z ID: SSU2000 Name: SSU_2000
The SSU2000 is in Normal Mode
3. Type bye and press the Enter key to log off.
No hardware changes are necessary.
Table 9-2. Files Required for Upgrading the Firmware
Item Number to
be Upgraded
Description
File for Module
Firmware Upgrade
File for Module
PLD/FPGA Upgrade
23413012-000-0
23413012-001-0
23413012-002-0
23413012-003-0
Comms Module 01200D00.DN1
01201B00.DN1
01202B00.DN1
01203B00.DN1
SCOMFPGA.DN9
23413015-000-0 Stratum 3E Clock Module 01500C00.DN1 SCLKFPGA.DN9
23413016-000-0 Stratum 2 Clock Module 01500C00.DN1 SCLKFPGA.DN9
23413279-000-0 CC Input Module 27900A00.DN1 SSUCCINP.DN9
23413158-000-0 CC Output Module 15800B00.DN1 SSUCCOUT.DN9
