12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 419
I/O Connector Grounding
ANTENNA A TNC J6 Shield: 0.01µF Bypass to Frame Ground Plane
ANTENNA B TNC J7 Shield: 0.01µF Bypass to Frame Ground Plane
SDU Interface DB25S J8
Body/Shield: Connected to Frame Ground Plane
SDU Backup Clk TBNC/BNO J9
Shield: Connected to Frame Ground Plane
I/0-1 Micro D50S J10
Body/Shield: Connected to Frame Ground Plane
I/0-2 Micro D50S J11
Body/Shield: Connected to Frame Ground Plane
I/0-3 Micro D50S J12
Body/Shield: Connected to Frame Ground Plane
I/0-4 Micro D50S J13
Body/Shield: Connected to Frame Ground Plane
I/0-5 Micro D50S J14
Body/Shield: Connected to Frame Ground Plane
I/0-6 Micro D50S J15
Body/Shield: Connected to Frame Ground Plane
I/0-7 Micro D50S J16
Body/Shield: Connected to Frame Ground Plane
I/0-8 Micro D50S J17
Body/Shield: Connected to Frame Ground Plane
I/0-9 Micro D50S J18
Body/Shield: Connected to Frame Ground Plane
RESET TBNC/BNO J19 Shield: 0.01µF Bypass to Frame Ground Plane
LG (Logic
Ground)
Stake-On TB3 & TB4 Terminal: 1.0µF Bypass to Frame Ground
Plane
Table D-9. I/O Connector Grounding (Continued)
Name
Connector
Type
Reference
Description
Termination Type
To Next Page
