12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 417
Signal Names and Definitions
ORING 13 Ring Connection of Output Signal # 13 41
OTIP 14 Tip Connection of Output Signal # 14 17
ORING 14 Ring Connection of Output Signal # 14 42
OTIP 15 Tip Connection of Output Signal # 15 18
ORING 15 Ring Connection of Output Signal # 15 43
OTIP 16 Tip Connection of Output Signal # 16 19
ORING 16 Ring Connection of Output Signal # 16 44
OTIP 17 Tip Connection of Output Signal # 17 20
ORING 17 Ring Connection of Output Signal # 17 45
OTIP 18 Tip Connection of Output Signal # 18 21
ORING 18 Ring Connection of Output Signal # 18 46
OTIP 19 Tip Connection of Output Signal # 19 22
ORING 19 Ring Connection of Output Signal # 19 47
OTIP 20 Tip Connection of Output Signal # 20 24
ORING 20 Ring Connection of Output Signal # 20 49
Table D-7. 50 Pin Connector Input/Output Signal Names and Location (Continued)
Name Description Connector Pin #
To Next Page
