Signal Names and Definitions
416 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
IRING 01 Ring Connection of Input Signal # 1 28
ITIP 02 Tip Connection of Input Signal # 2 13
IRING 02 Ring Connection of Input Signal # 2 38
ITIP 03 Tip Connection of Input Signal # 3 23
IRING 03 Ring Connection of Input Signal # 3 48
OTIP 01 Tip Connection of Output Signal # 1 2
ORING 01 Ring Connection of Output Signal # 1 27
OTIP 02 Tip Connection of Output Signal # 2 4
ORING 02 Ring Connection of Output Signal # 2 29
OTIP 03 Tip Connection of Output Signal # 3 5
ORING 03 Ring Connection of Output Signal # 3 30
OTIP 04 Tip Connection of Output Signal # 4 6
ORING 04 Ring Connection of Output Signal # 4 31
OTIP 05 Tip Connection of Output Signal # 5 7
ORING 05 Ring Connection of Output Signal # 5 32
OTIP 06 Tip Connection of Output Signal # 6 8
ORING 06 Ring Connection of Output Signal # 6 33
OTIP 07 Tip Connection of Output Signal # 7 9
ORING 07 Ring Connection of Output Signal # 7 34
OTIP 08 Tip Connection of Output Signal # 8 10
ORING 08 Ring Connection of Output Signal # 8 35
OTIP 09 Tip Connection of Output Signal # 9 11
ORING 09 Ring Connection of Output Signal # 9 36
OTIP 10 Tip Connection of Output Signal # 10 12
ORING 10 Ring Connection of Output Signal # 10 37
OTIP 11 Tip Connection of Output Signal # 11 14
ORING 11 Ring Connection of Output Signal # 11 39
OTIP 12 Tip Connection of Output Signal # 12 15
ORING 12 Ring Connection of Output Signal # 12 40
OTIP 13 Tip Connection of Output Signal # 13 16
Table D-7. 50 Pin Connector Input/Output Signal Names and Location (Continued)
Name Description Connector Pin #
