12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 279
TL1 Command Interface
RTRV-DATA-LRMBPV:[tid]:[aid]:
ctag;
Valid aid code: ALL, SxA[y[-z]]
This command returns the BPV data (current operating
mode and status) of an LRM module or port. The format of
response message is:
^^^"aid:ttime,60srate,24hrate,es,ses,sesr" <cr lf
>
where:
module aid and the port
ttime accumulates how much time (integer) in seconds
since the last BPV Clear command was issued
60srate = BPV error rate (float value) per second in a
60-second window
24hrate = BPV error rate (float value) per second in an
86400-second window
es indicates (integer) that the BPV accumulates BPV
Errored Seconds (BPV-ES) when any seconds have a
BPV error
ses indicates (integer) that the BPV accumulates BPV
Severely Errored Seconds (BPV-SES) when any
seconds have a severely BPV error
sesr = BPV Severely Errored Ratio (float value).
Table B-5. TL1 Retrieve Commands (Continued)
Command Description
