12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 281
TL1 Command Interface
RTRV-DATA-MTIE-HIST:[tid]:aid
: ctag[::[clksrc][,count];
Valid aid code: S1Ay-z
This command returns the Historical MTIE data for an input
port. The Historical MTIE data is the 24-hour MTIE data
stored every day at midnight. There are 99 Historical MTIE
records stored. The command requires an aid to identify the
input port to report data from. The optional parameters are
the clock identifier and the number of day(s) of MTIE history
to be retrieved from the current day (day 0). If no clock
source [CLK-A|CLK-B] i
s specified, the current output clock
will be used. The response will be the complied message
followed by the requested data. The format for each response
message line is:
^^^”aid:ocrdat,ocrtm,MTIE,clksrc,monval1,monval2,
.., monval8”<cr lf>
where:
ocrdat and ocrtm = beginning date and time the data
was collected
clksrc = clock A or B used for the measurements
monval? = the data value for the time period, given in
nanoseconds. There are eight monvals in sequence, and
the time periods in sequence are 0.05, 0.1, 1, 10, 100,
1000, 10000, and 100000.
Table B-5. TL1 Retrieve Commands (Continued)
Command Description
