TL1 Command Interface
294 SSU-2000 User’s Guide 12713020-002-2 Revision D – April 2004
RTRV-PRMTR-GPS:[tid]:[aid]:
ctag;
Valid aid code: S1A3 or S1A5 (must be a GPS module)
This command returns the settings for the GPS module
designated by the aid.
The format for each response message line is:
^^^"aid:pri,pql,sigma" <cr lf>
where:
pri = priority setting of [0 through 10, with 0 = MON]
pql = priority quality level [1 – 16]
sigma = limit of the noise measurement [10 – 1000 ms]
RTRV-PRMTR-INPUT:[tid]:[aid]:
ctag;
Valid aid code: ALL, S1Ay[-z]
This command returns the settings for the input designated
by the aid. This reports the input module settings.
The format for the response message is:
^^^"aid:pstate,pri,pql,mode,ssm,zs,crc,gain,
csflt,bit" <cr lf>
where:
aid = port aid
pstate = port enabled state [ON|OFF]
pri = priority 1 (highest) through 10 (lowest) or MON for
monitor
pql = provisioned priority quality level of 1 through 16
mode = framing type or clock frequency in MHz:
[ESF|D4|CCS|CAS|1|1.544|2.048|5|10]
ssm, zs, crc, and gain = [ON|OFF]
csflt = [HI|LO|OFF|NA]
bit = bit number 4 through 8 of the Time Slot 0 word
used for the E1 sync status message
RTRV-PRMTR-IP:[tid]::ctag;
Valid aid code: None
This command returns the current Internet Protocol settings
for the unit.
The format of the response message is:
^^^"aaa.aaa.aaa.aaa,mmm.mmm.mmm.mmm,
ggg.ggg.ggg.ggg"<cr lf>
where:
aaa.aaa.aaa.aaa = IP address of unit
mmm.mmm.mmm.mmm = IP mask of unit
ggg.ggg.ggg.ggg = IP gateway of unit
Table B-5. TL1 Retrieve Commands (Continued)
Command Description
To Next Page
