12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 405
Antennas
Installing Antennas
5. Wrap the connectors with weatherproof tape for added protection.
6.
Verify that the antenna coaxial cable center conductor is not shorted to the shield of
the cable
.
Cabling the GPS Antenna
To route the coaxial cable of the mounted antenna (see Figure C-1):
1.
Loosen the four screws securing the top of the antenna in place to gain access to the
connector
.
2. Route the shorter antenna coaxial cable from the antenna through the floor
flange (in the lower half of the antenna base) to the unit.
3. Connect the cable to the antenna and run the cable from the antenna through the
slot of the floor flange.
4. Replace the four screws to secure the top of the antenna in place with the cable
connected.
Mounting the GPS Antenna
To mount the GPS antenna:
To mount the antenna to any stable flat surface, use the floor flanges supplied in
the GPS Antenna Kit. The mounting surface and the local building codes
determine the type and number of fasteners, screws, bolts, and so forth, that may
be required.
To mount the antenna on the side of a building or tower, use the optional right
angle mounting bracket (part number 12010210-000-0).
To secure the coaxial cable to the mast, use one or more 8-inch cable ties or
appropriate cable clamps.
Recommendation: Symmetricom does not recommend soldered
connections for grounding purposes. All grounding connections
should be secured with mechanical clamp connectors.
Caution: To avoid damage to the connectors, do not use the
connectors to pull the cable. If at all possible, avoid bundling the
coaxial cable with other cables (and possible noise sources). Use
appropriate cable-pulling devices when pulling the coaxial cable
through conduit or a weather head.
Caution: To avoid damage to internal solder connections, do not
over-tighten the connector.
