12713020-002-2 Revision D – April 2004 SSU-2000 User’s Guide 439
SSU-2000 Shelf Specifications
Temperature
Storage
–25C to +55C Duration <12 months
GR-63-CORE Sec. 4.1.1 ETS 300 019-1 Class 1.2
Relative Humidity
Storage
5% to 100% Non-condensing. Duration <12 months
GR-63-CORE Sec. 4.1.1 ETS 300 019-1 Class 1.2
Temperature Transporting -40C to +70C Duration <3 months
GR-63-CORE Sec. 4.1.1 ETS 300 019-1 Class 2.3
Chassis Environmental
Relative Humidity
Transporting
5% to 100% Non-condensing. Duration <3 months
GR-63-CORE Sec. 4.1.1 ETS 300 019-1 Class 2.3
Heat Dissipation GR-63-CORE Sec. 4.1.4
Altitude 200 ft. below to 13,000 ft above sea level GR-63-CORE Sec.
4.1.3
Airborne Contaminants GR-63-CORE Sec. 4.5.2.1
Shock Operational ETS 300 019-2-3 Class T3.1
Sinusoidal Vibration
Operational
GR-63-CORE Sec. 4.4.3
Seismic Vibration GR-63-CORE Sec. 4.4.1 Earthquake Zone 4 ETS 300
019-2-3-A1
Shock Transporting ETS 300 019-2-2 Class T2.2
Sinusoidal Vibration
Transporting
GR-63-CORE Sec. 4.4.4 fig. 4-3
Random Vibration Transporting ETS 300 019-2-2 Class 2.1, 2.2, 2.3, and 2.3 special
Packaged Equipment Shock GR-63-CORE Sec. 4.3.1.2
Unpackaged Equipment Shock GR-63-CORE Sec. 4.3.2
Electrical Safety GR-1089-CORE Sec. 7
Material/Component Fire
Resistance
GR-1089-CORE Sec. 4.2.3.1
EMC
Immunity/Resistibility ESD EN 300 386-2 V1.1.3 Sec. 5.1.1.1 & 5.1.1.4
GR-1089-CORE Sec. 2
Immunity Radiated EN 300 386-2 V1.1.3 Sec. 5.1.1.2
GR-1089-CORE Sec. 3.3.1 & 3.3.2
Immunity Fast Transient EN 300 386-2 V1.1.3 Sec. 5.1.3.1 & 5.1.5.1
Immunity Surges EN 300 386-2 V1.1.3 Sec. 5.1.3.2
Table F-1. General Specifications (Continued)
Characteristics Specification
