Note
The master commands a torque but internally it is computed as current. In most cases, as the position
or velocity is the controlled value, the current measurement is sufficient. If a precise torque is required
by the application, it should be verified with a torque sensor.
3.1.8.1.1.1.1 General Scope of the Torque Controller
The task of the torque controller is to make sure that the torque currently produced by the motor
corresponds to the desired torque. This makes it one of the core algorithms of servo drives. It is used
whenever a motor is driven.
In general, the RMS value of motor phase currents are proportional with the generated torque. The ratio
between these two is known as torque constant k_T (as defined in subitem 0x2003:2).
The torque control loop is executed at a frequency of 16 kHz (as of firmware v4.2.0).
3.1.8.1.1.1.2 Reference Torque Generation
The reference torque can be updated in every execution step. In cyclic synchronous torque mode, the
reference torque is transferred directly from the EtherCAT master to the torque controller via the PDO (object
0x6071). In other modes, a position or velocity controller is running on the SOMANET Drive and acts as higher
level control, so their outputs act as reference for the torque controller. The offset torque 0x60B2 is also part
of the reference torque as described in Torque Offset
3.1.8.1.1.1.3 Functional Description and Controller Structure
The following figure represents the structure of the torque controller. The implemented torque control
algorithm is based on field oriented control (FOC).
