Sysmex XP-300 14-13
Technical Information
Revised July 2013
Bar code reader settings
Make settings according to the menu sheet which is provided with
the bar code reader.
Communications parameters were set at the time the unit was
shipped from the factory. They do not need to be set.
Make settings to match the bar code label which you use.
Set the ID character and check digit to “Not transmit”.
Hardware specifications
(1) Symbologies which can be read: UPC-A/E, CODE39,
CODE128, ITF, NW-7
(CODABAR)
(2) Decoder: Built-in
(3) Interface: RS-232C
(4) Connector: DIN 8P
(5) Power input: 5 V DC ±5%
(6) Connector pin arrangement
No. Signal name Signal direction
1 TxD (Transmit Data) Reader → Analyzer
2 RxD (Receive Data) Reader ← Analyzer
3 RTS (Request To Send) Reader → Analyzer
4 CTS (Clear To Send) Reader ← Analyzer
5 NC (Not Connected)
6 DTR (Data Terminal
Ready)
Reader ← Analyzer
7 SG (0 V) Reader – Analyzer
8 +5 V (+5 V) Reader ← Analyzer
