SYSMEX XP Series - Left Side Interior

3-6 Sysmex XP-300
Design and Function
Revised July 2012
3.6 Left side interior
(1) Waste chamber
Collects waste from transducers and mixing chambers.
(2) Pneumatic unit
Supplies pressure and vacuum.
(2) Pneumatic unit
(1) Waste chamber
Note:
Do no open the instrument cover unless your Sysmex service representative asks you to.
