5-4 Sysmex XP-300
Initial Operation
Revised July 2012
5.3 Preparation of installation location
To ensure that the instrument performs to its full extent, it should be installed at an appropriate place.
• Select a place where the power supply is conveniently located.
• Do not place any heavy objects on top of the instrument.
• Secure a space for maintenance and service. Giving consideration to heat radiation by the
instrument, provide at least 50 cm clearance between the wall and the instrument’s side, rear and
top panels.
You may need some more desktop space if an optional graphic printer is connected.
The dimensions of the instrument are shown below. The power cord is 1.8 m long.
Width (mm) Depth (mm) Height (mm) Weight (kg)
Main unit 420 355 480 30
