Sysmex XP-300 13-7
Troubleshooting
Revised July 2012
13.3 Error messages, possible causes and actions to revolve the error
1. Pressure/Vacuum Errors
An error subcode may be displayed after the error code.
The subcode is for Sysmex service representative use only.
Error Message
(Error Code)
0.05MPa Pressure Error (113005)
Cause Pressure was not within the monitored range (0.039 - 0.059 MPa) due to the
following reason(s):
• 0.05 MPa pressure adjustment error
• Pneumatic unit pressure error
• Air leakage from pressure line
Action Adjust pressure to 0.05 MPa.
Current pressure will be displayed real-time on the LCD screen. Adjust pressure
by referring to “Adjusting pressure to 0.05 MPa” in “12.15 Adjust pressure and
vacuum”.
Troubleshooting
on the screen
After adjustment and checking, press the [Back] button to
clear the error and perform the recovery process.
Note • The analysis result with an error is masked on the screen.
• The status is not ready for analysis, but the processing, etc. of stored data can
be performed.
Error Message
(Error Code)
–0.0333MPa Vacuum Error (114010)
Cause Vacuum was not within the monitored range ((–0.0307) - (–0.0360) MPa) due to
the following reason(s):
• –0.0333 MPa vacuum adjustment error
• Fluid back-flows into the trap chamber
• Pneumatic unit vacuum error
• Air leakage from vacuum line
Action • Adjust vacuum to –0.0333 MPa.
Current vacuum will be displayed real-time on the LCD screen. Adjust
vacuum by referring to “Adjusting vacuum to –0.0333 MPa” in
“12.15 Adjust pressure and vacuum”.
• Discard fluid in Trap Chamber.
Discard fluid if collected. Refer to “12.4 Check trap chamber level and
discard”.
Troubleshooting
on the screen
After adjustment and checking, press the [Back] button to
clear the error and perform the recovery process.
Note • The analysis result with an error is masked on the screen.
• The status is not ready for analysis, but the processing, etc. of stored data can
be performed.
To Next Page
