SYSMEX XP Series - Calibration Flow Chart

10-2 Sysmex XP-300
Calibration
January 2012
10.1 Calibration flow chart
HGB/HCT calibration start
Analyze samples by the reference method to determine
reference value (target value).
Automatic calibration: 5 samples
Manual calibration: Over 5 samples
Page 10-3
Automatic
calibration
Manual
calibration
Select automatic calibration
mode and parameter.
Enter target value.
Perform analysis
(* in whole blood mode).
Update calibration value.
Page 10-4
Page 10-6
Page 10-7
Page 10-8
Calculate calibration value.
• Calculate a mean of reference values.
• Perform analysis (* in whole blood mode).
• Calculate a mean of analysis values.
• Calculate calibration value.
Page 10-9
Update calibration value.
• Select manual calibration mode.
• Enter calibration value.
Page 10-10
Completion of HGB/HCT calibration
