Bus setups Set up a MIPI CSI-2 serial bus
Learnhowtosetupan8B10BSerialBus(see page 111)
Learn how to set up a CAN Bus (see page 115)
Learn how to set up a MIL-1553 Bus (see page 120)
LearnhowtosetupanEthernetBus(see page 121)
Learn how to
set up an Custom serial bus.
(see page 586)
Learn how to troubleshoot a serial bus. (see page 595)
Learn how to view analog characteristics of a digital waveform. (see page 579)
Learn how to trigger on a bus. (see page 658)
Learn to view the bus packets. (see page 153)
Set up a MIPI CSI-2 serial bus
NOTE. MIPI CSI-2 serial bus setup is available only on instruments with the SR-DPHY option.
From the Bus Setup window in the Config tab, select a bus from the Bus list and then select the MIPI
CSI-2 Serial bus type.
NOTE. The Components for the MIPI CSI-2 bus standard are set by the instrument.
For information o n the controls, click the buttons.
