Bus setups Select the RS-232 bus parity

Select the RS-232 bus parity

NOTE. The RS-232 B us Parity option is available on instruments with option SR-COMP.

From the Bus Setup window, select the Select tab and the RS-232 Serial bus type.

To use

Scroll through the Bus list and select the RS-232 bus to conﬁgure.

Click the Parity box and select the parity from the drop-down list.

Behavior

Set the bus parity selection to:

None, the default.

Odd.

Even.

NOTE

. There is no parity selection when the number of data bits is 9.

What do you want to do next?

Learn more about b us setups. (see page 95)

Learn a bout bus conﬁguration. (see page 148)

Learn about digital setups. (see page 87)

134 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
