Bus setups Set up a Custom serial bus
Learn a bout bus configuration. (see page 148)
Learn about digital setups. (see page 87)
Learn how to set up an I2C serial bus. (see page 582)
Learn how to set up an SPI serial bus. (see page 582)
Learn how to
set up a USB serial bus.
(see page 584)
LearnhowtosetupanRS-232serialbus. (see page 583)
Learn how to set up a MIPI DSI1 Serial Bus (see page 584)
Learn how to set up a MIPI CSI2 Serial Bus (see page 585)
Learn how to set up an 8B10B Serial Bus (see page 111)
Learn how to set up a CAN Bus (see page 115)
Learn ho
w to set up a MIL-1553 Bus
(see page 120)
Learn how to set up an Ethernet Bus (see page 121)
Learn how to set up an Custom serial bus. (see page 586)
Learn how to troubleshoot a serial bus. (see page 595)
Learn how to view analog characteristics of a digital waveform. (see page 579)
Learn how to trigger on a bus. (see page 658)
Set u
p a Custom serial bus
NOTE. Custom serial bus setup is available o nly on i nstruments with the SR-CUST option.
Fr
om the Bus Setup window, select Serial from the Bus Type list and then select the Custom Serial bus type.
NOTE. The Components for the Custom bus standard are set by the installed custom decoder.
F
or information on the controls, click the buttons.
112 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
