Tektronix DPO5000 Series User Manual

File Menu SetupActionOnEvent
SetupActionOnEvent
From the File menu, select Action On Event.
Overview
Use this control w indow to set up the action (save or e-mail) to perform when an event (trigger, limit
test failur
e, or mask test failure) occurs.
To use
1. From the On the event of drop down list, select the event that will cause the action.
2. Click the Save check box to save a file when the event occurs.
3. Click the Send E-mail check box to send an e-mail when the event occurs.
4. To change the s etup of either action, click its Setup button.
What do you want to do next?
Learn about Email on Event setup (see page 552)
LearnaboutSaveOnEventSetup(see page 528)
Set up Save On Event
From the File menu select Action On Event, and then click Save Setup.
528 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
