Oscilloscope Reference Acquisition preview
Linear. Provides linear interpolation of the waveform.
What do you want to do next?
Learn about waveform display and the time base. (see page 722)
Learn about using the MultiView Zoom feature. (see page 724)
Go to a step-
by-step procedure for displaying waveforms.
(see page 662)
Acquisition preview
The acquisition preview attempts to show what the next acquisition will look like when the acquisition
is delaye
d due to slow triggers or long acquisition duration, or when the acquisitions have stopped.
Acquisition preview recalculates math waveforms, but does not represent changes in trigger levels, trigger
modes, or different acquisition modes.
Acquisition preview has some limitations. For example, if the h orizontal scale is changed to a setting that
is significantly faster or slower, the waveform display is are cleared.
NOTE. There is no acquisition preview in Fast Acquisitions mode.
What do you want to do next?
Learn
more about waveform display.
(see page 720)
Learn about waveform d isplay and time base. (see page 722)
Go to a step-by-step procedure for displaying waveforms. (see page 662)
Waveform display
The instrument uses the following methods to display waveforms:
Defines the waveform (math and reference waveforms only).
Enables the waveform display.
T
he following table summarizes this process as it applies to the different types of waveforms.
720 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
