Horizontal and acquisition setups Horizontal Position/Scale control window
Horizontal Position/Scale control window
From the Horiz /Acq menu, select Position/Scale.
Overview
Use the Horizontal control window to set the horizontal position and scale of displayed waveforms.
For information on the controls, click the buttons.
To use
Click the Delay Mode button to toggle the horizontal delay on (see page 181).
Behavior
You ca n
use this control window to turn on horizontal delay so the a cquisition window can be focused on
events that occur a t a fixed delay after the trigger point.
NOTE. The dedicated Horizontal controls on the front panel also perform the same functions.
What do you want to do next?
Lear
n more about the Horizontal Position controls.
(see page 832)
Learn more about the Horizontal Scale controls. (see page 833)
Learn more about the Horizontal Delay Mode. (see page 832)
Learn m ore about the Horizontal controls. (see page 193)
180 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
