Utilities User Preferences: Front Panel Buttons
User Preferences: Front Panel Buttons
From the Utilities menu, select User Preferences; then open the Front Panel Buttons tab.
Overview
Use the Front Panel Buttons tab to set the function of the Print and the Default Setup buttons.
To use
Click the Set Front Panel Print Button to change the function of the front panel Print button to save
a file each time you push the button.
To select a saved setup for the oscilloscope to recall when you push the Default Setup front panel button:
Select Factory from the list to recall the Factory setup.
Select a saved setup (from Setup 1 through Setup 10) to recall a specificsetup.
Behavior
When the Set Front Panel Print Button is not selected, the function of the front panel Print button is to
print. When you select the alternate save function for the Print button, the oscilloscope updates the File
Save As menu (under the File menu) for the selected file type.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 561
