Horizontal and acquisition setups Horizontal Position/Scale control window: delay mode on
Horizontal Position/Scale control window: delay mode on
From the Horiz /Acq menu, select Position/Scale.
Overview
Use the Horizontal control window to set the horizontal delay and the horizontal scale of the displayed
waveforms w
hen the horizontal delay is on.
For information o n the controls, click the buttons.
To use
Click th
e Delay Mode button to toggle the horizontal delay on or off.
Behavior
You can use this control window to turn on horizontal delay so the acquisition window can be focused on
events that occur at a fixed delay after the trigger point.
NOTE. The dedicated Horizontal controls on the front panel also perform the same functions.
What do you want to do next?
Learn more about the Horizontal Delay Mode. (see page 834)
Lea
rn more about the Horizontal Scale controls.
(see page 835)
Learn m ore about the Horizontal controls. (see page 193)
Horizontal/Acquisition control window (Acquisition tab)
From the Horiz /Acq menu, select Horizontal/Acquisition Setup; then open the Acquisition tab.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 181
