Tektronix DPO5000 Series User Manual

File Menu Sa ve As Dia l og Box: Use r Mask
What do you want to do next?
Learn about saving a waveform. (see page 537)
Save As Dialog Box: User Mask
From the File menu, highlight Save As; then select User Mask from the submenu.
Overview
Use this dialog box to save user masks. Masks are saved in C:\Use rs\[Username]\Tek-
tronix\TekScope\Masks
unless you choose another folder.
To use
To save the mask with the default file name, click the Save button.
To enter a different file name, click the keyboard icon and use the pop-up keyboard to enter a unique file
name. T he extension specified in the Save as type list will automatically be appended to the file name.
Behavior
The Save As dialog box displays when you click Save in the Edit Mask control window. The mask is
saved in the format specified in the Save as type list.
536 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
