How to ? Create a math waveform with the Equation E ditor

Create a math waveform with the Equation Editor

Use the following steps to create math waveforms using the Equation Editor:

1. Open the Math Setup control window by clicking Math on the toolbar, or by selecting Math Setup in

the Math menu.

2. In the Math Setup control window, click the Editor button to open the Math Equation Editor.

3. Select a Math waveform from the drop-down list.

4. Select a math function by clicking a button under the tabs on the left side of the Equation Editor (for

example, click Derivative).

5. Select a valid waveform to use as an operand from the Channels Selector

(see page 258).

6. Use other

buttons in the Equation Editor as necessary to create the math expression for the math

waveform.

7. Click OK

to create and display the math waveform.

DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 611
