Bus setups Select the USB serial bus speed
Select the USB serial bus speed
NOTE. USB serial bus Speed selection is available only on instruments with option SR-USB.
From the Bus Setup window, select Serial from the Bus Type list and then select the USB Serial bus type.
To use
To change the speed for the displayed component of the bus, click Speed and select from the cascading list.
Behavior
The instrument acquires data from the channel you select for each component.
What do you want to do next?
Learn
more about bus setups.
(see page 95)
Learn about bus configuration. (see page 148)
Learn about digital setups. (see page 87)
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 125
