Trigger setups Visual trigger
Return to the Trigger Setup control window. (see page 385)
Visual trigger
From the Trig menu, select Visual Trigger Setup. Visual triggers are optional.
Overview
Use the Visual Trigger control window to control which triggered w aveforms are displayed. For example,
the following screen capture shows a waveform acquired using edge trigger.
The following screen capture shows the same waveform acquired using edge trigger and visual trigger
with two visual trigger areas controlling which triggered waveforms are displayed.
Use the Visual Trigger control window to control which triggered waveforms are d isplayed.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 459
