Tektronix DPO5000 Series User Manual

Oscilloscope Reference Saving and recalling setups
T1 values
The T1 values are vertical and horizontal values associated with the left-most crossing point. These
areas are used to establish the following values:
TCross
1
Mean. This is the horizontal mean of the left-crossing point at TCross
1
.
TCross
1
Sigma. This is the horizontal standard deviation of the left-crossing point at TCross
1
.
TCross
1
Peak-to-Peak. This is the horizontal peak-to-peak deviation of the left-crossing point at
T
Cross
1
.
PCross
1
Mean. This is the vertical mean of the left-crossing point at PCross
1
.
T2 values
The T2 values are vertical and horizontal values associated with the right-most crossing point. These
areas are used to establish the following d irections:
TCross
2
Mean. This is the horizontal mean of the right-crossing point at TCross
2
.
TCross
2
Sigma. This is the horizontal standard deviation of the right-crossing point at TCross
2
.
TCross
2
Peak-to-Peak. This is the horizontal peak-to-peak deviation of the right-crossing point
at TCross
2
.
DCD values
The duty cycle distortion (DCD) values are horizontal values associated with the right-most c rossing point
at 50% of the eye height. These areas are used to establish DCD
pk-pk
, the horizontal peak-to-peak deviation
of the left-crossing point at half the h eight of the eye.
What do you want to do next?
Learn a bout communication triggering. (see page 704)
Go to mask testing setup overview. (see page 209)
Saving and recalling setups
This instrument can save a n umber of different instrument setups for later recall, limited only by the
space that you have to store the setups.
By saving and recalling different setups, you can switch from setup to setup without having to first
manually record your settings and then manually set them. This capability is helpful when you want to:
Save and recall a setup that optimizes the instrument for displaying and analyzing a certain signal
Save a series of setups to help automate a procedure through recall of a sequence of saved setups
as part of performing the procedure
Save a s etup for sharing with a second instrument
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 785
