Bus setups Selec t the USB bus threshold
Select the USB bus threshold
From the Bus Setup window, select Serial from the Bus Type list and then select USB Serial b us type.
NOTE. USB bus threshold high and low are available only on instruments with option SR-USB.
To use
To change the voltage high or low threshold level of the component Input, click or
entry box respectively and use the keypad to enter a value or use the multipurpose knobs to
select a voltage level. Setting the low threshold is only available when the signal type is differential.
Behavio
r
The instrument acquires data from the channel you select for each component.
What do you want to do next?
Learn more about bus setups. (see page 95)
Learn about bus configuration. (see page 148)
Learn about digital setups. (see page 87)
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 129
