About Tektronix oscilloscopes Creating your own control windows
Trigger level marker
Visual trigger area
Readouts(themenuvarieswith the type of readout)
Graticule
Control win
dow
Entry boxes
Regions (Menu bar, Toolbar, Multipurpose Knobs)
Creating your own control windows
For quick access to the controls that you use most often, you can create your own MyScope control
window (see page 379). Choose from a list of controls to include, and make each control window
unique to your needs.
MyScopeallowsyoutohaveuptoeighttabs in a control window, increasing the flexibility and ease of use
for your unique MyScope control windows. You can create and save any number of control windows for
future
use.
Initialize the instrument
After you complete a task, you may want to initialize the instrument settings before using the instrument
with
your next task. This may be especially important if you share the instrument with others; previous
settings may make it difficult for you to perform the required task.
To q
uickly restore the instrument to its default settings, push the front-panel Default Setup button.
If data security is important to you, use the TekSecure Erase feature to overwrite all internal waveform and
se
tup memory with null values.
44 DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series
