Tektronix DPO5000 Series User Manual

File Menu Recall Dialog Box: Instrument Setups
Use the pop-up keyboard to enter a File name, or click the file name to select it.
TIP. If you do not see the file that you want to recall, verify that the Files of type list shows the correct
file format. Yo
u may also need to check other folders if the file was stored in a location other than the
C:\Users\[Username]\Tektronix\TekScope\Waveforms folde r.
Behavior
This dialog box opens when you click Recall from the File menu or when you click the Recall button from
the Reference wave form controls. Waveforms are stored in WFM file format, which is an internal format
of the instrument. When you click Recall, the Ref 1-4 waveform is displayed in the graticule.
NOTE. When you recall a reference waveform, a temporary file containing the waveform data is written to
C:\Users
\[Username]\Tektronix\TekScope\Waveforms. The file is named TDS_REF n.WFM, where n is the
reference waveform number. This fi le is deleted when the reference waveform is deleted.
What do y
ou want to do next?
Learn about saving a waveform to a file. (see page 537)
Learn about deleting waveform files. (see page 527)
Recall Dialog Box: Instrument Setups
From File menu, select Recall, or from the Reference Waveform controls (see page 523), click the Recall
button.
Overview
Use the Recall dialog box to recall an instrument setup.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 525
