Trigger setups Set up an SPI bus trigger
Name Address
General Call
0000 000 0
START Byte
0000 000 1
HS-mode
0000 1XX X
EEPROM
1010 XXX X
CBUS
0000 001 X
xxx
What do you
want to do next?
Learn about bus setups. (see page 95)
Set u p an SPI bus trigger
NOTE. The Bus Trigger Control Window for SPI Serial option is available only on instruments with
option
SR-EMBD.
From the Trigger menu, select the Bus setup.
Over
view
Use the controls to set up the SPI Bus parameters.
To use
For
information on the controls, click the buttons.
DSA/DPO70000D, MSO/DPO/DSA70000C, DPO7000C, and MSO/DPO5000 Series 397
